800kw Hydroelectric Pelton Wheel Micro Hydro Generator

Name: 800kw Hydroelectric Pelton Wheel Micro Hydro Generator
Brand: Forster
Price: 145800 USD

Wholesale 800kw Hydroelectric Pelton Wheel Micro Hydro Generator from china suppliers

Brand Name : Forster

Model Number : CJA475-W-92/1×8

Certification : SGS/CE/TUV/ISO9001

Place of Origin : Sichuan, China (Mainland)

MOQ : 1 Set/Sets

Price : USD145800/set

Payment Terms : L/C, T/T

Supply Ability : 50 Set/Sets per Month

Delivery Time : 120days

Packaging Details : Wood box

Capacity : 800kw

Voltage : 400v

Frequency : 50Hz/60Hz

Generator type : Brushless Excitation

Power Factor : cos 0.8lag

Governor : High Hydraulic Microcomputer Governor

Runner material : stainless steel

Keyword : pelton turbine

Insulation class : F/F

Installation method : Horizontal installation

Contact Now

High efficiency 800kw Pleton Turbine for Hydroelectric Generator

Product features:

Pelton Turbine's power generation can range from 50kW to 500MW, and can be applied to a large head range of 30m to 3000m, especially in the high head range. Other types of turbines are not applicable, and there is no need to build a dam, no downstream draft pipe construction, and construction. The fund is only a fraction of other types of hydro-generator set 2 and has very little impact on the natural environment.
Pelton Turbine can save the harsh requirements of pressure over-flow channel and sealing because the runner runs in the runner chamber under atmospheric pressure. It is widely used for high efficiency and smooth changes in operating conditions. It is another reason for its charm. .
Due to the above advantages, the development theme of Pelton Tubrine is being paid attention to by the world.
In addition, Pelton Tubrine has high efficiency and relatively stable power generation, and is particularly suitable for installation in high-head areas in mountainous areas.

800kw Pelton Tubrine Parameters:

Product name:800kw Pelton Turbine Generator Unit
Technical Parameters
Net Head:	Hr	300	m
Flow Rate:	Q	0.33	m³/s
Capacity	P	1*800	kw
Turbine		Generator
Model	CJA475-W-92/1×8	Model	SFWE-W800-8/1180
Unit Flow Q11	0.0202m3/s	Rated Efficiency of Generator ηf	93.5%
Unit Rotating Speed n11	39.13r/min	Efficiency of the generator f	50Hz
Max Hydraulic Thrust Pt	/	Rated voltage of generator V	400V
Rated rotating speed r	750r/min	Rated current of the generator I	1443A
Efficiency of turbine ηm	89.5%	Excitation	Brushless Excitation
Max Runway speed nfmax	1296r/min	Connection way	direct connect
Rated Output Nt	856kW	Max runaway speed nfmax‘	1296r/min
Rated Discharge Qr	0.33m3/s	Rated rotating speed nr	750r/min
Turbine real machine efficiency ηr	87%	Unit support form	Horizontal 2 point

Product pictures:

800kw Hydroelectric Pelton Wheel Micro Hydro Generator

Pelton Turbine Design Schematic:

Company Information

Engineering case:

FAQ

Q1, Which hydro turbine should I choose?

Please tell me the water head, flow rate, frequency, Total power you need

, voltage, on grid or off grid operation, we will propose a solution.

Q2, Can your factory provide all the equipment for hydropower generation?

Yes, we can provide you with turbines, hydro-generators, pressure regulators, turbine wheels, control panels, transformers, monitoring systems and more.

Q3, Can you do EPC for a hydroelectric power plant?

Yes, we can provide TURN-KEY and EPC services including measurement, design, manufacturing, construction, manufacturing, commissioning, inspection, maintenance runner replacement and refurbishment/upgrade/improvement/repair/refurbishment of turbines/generators including bearings, seals For parts and key parts, we will send technicians and workers to install equipment.

Q4, Is your company a trading company or a manufacturer?

We are a manufacturer of hydro turbine generators and started to promote the international market in 2013. Our factory is located in Sichuan, where China's water conservancy and hydropower is most developed. Welcome to visit our factory in China.

Q5, How many an acceptable MOQ?

For this product, our acceptable MOQ is 1 set.

Q6, How long is the delivery time?

Delivery times range from 15 days to 6 months depending on the model you are purchasing.

Q7, Does your company have its own independent official website?

Of course, and we can see more information about our company and products on our official website.
